532nm 5mW Uniform Line Laser
Features:
· Wide Temperature Range
· Uniform Line
· Customized Housing Shape
· High Reliability
Product Details:
532nm 5mW Line Laser Module
The LASENCE G532L006-14.5x32-90-(-10-50)-10 green line laser module is a high-quality OEM product, featuring a wide operating temperature range (-10~50℃), fast response (typical rise time of 0.05s), and high reliability. It adopts a brass housing, outputs a 532nm Uniform beam, with a line width of approximately 10mm at 10 meters. It has stable power and supports customized fan angles. Compatible with 2.3-5.0V DC voltage, it is compact (14.5×32mm) and lightweight, allowing flexible integration into various devices to meet the needs of precise positioning and indication in multiple scenarios.
Product Specifications:
| Specification | G532L006-14.5x32-90-(-10-50)-10 |
| Wavelength | 532 ±2 nm |
| Output Power | 4-6mW |
| Line Width at 10m | <10mm |
| Fan Angle | 60° |
| Laser Drive Modes | CW |
| Operating Temperature (℃) | -10 to 50 |
| Storage Temperature (℃) | -20 to 60 |
| Opearting Voltage (DC, V) | 3V |
| Weight (g) | ≤ 20 |
| Lifetime (hours) (MTTF at 25℃) | >10000 |
