405nm Uniform Line Laser Module
Features
· 405nm Laser
· High Reliability
· Uniform Line
· Wide Temperature Range
Product Details:
B405L050-13x50-60-(-10-85)-CW
LASENCE’s B405L050-13x50-60-(-10-85)-CW is an OEM-customizable 405nm line laser module (Class 3B). It has 40-60mW output (typ.50mW), -10~85℃ operating temp, ≤1mm linewidth@700mm, 10-14V DC input, and RoHS compliance. The aluminum-housed module ensures durability, fit for industrial alignment/measurement.
Product Specifications:
| Specification | B405L050-13x50-60-(-10-85)-CW |
| Wavelength | 405 ±5 nm |
| Output Power | 40-60mW |
| Line Width at 700mm | <1mm |
| Line Length at 700mm | 680-840mm |
| Line Uniformity | ≥ 70 |
| Power Type | CW |
| Operating Voltage | 10-14V |
| Operating Current | < 90mA |
| RoHS Compliance Declaration | Yes |
